| Model | Leguan 125 |
|---|---|
| Working Height | 12.5 m |
| Platform Height | 10.5 m |
| Horizontal reach | 6.3 m |
| Safe working load | 200 kg |
| Transport length | 5.0 m |
| *Without Platform | 4.4 m |
| Overall Height | 1.80 m |
| *Normal Tyres | 1.03 m |
| *Narrow Tyres | 0.95 m |
| *Rubber Tracks | 1.12m |
| Gradeability | 35 % |
| Stabilizer Spread | 3.0 x 3.2 m |
| Weight with tyres | 1500 – 1800 kg |
| Drive | 4WD or tracks |
